ZXK-45 main motor stepless frequency control, the level of second gear speed gear shift points. Screw the ball screw axis, X, Y, Z axis drive unit Direct. Lubrication system, rail surface plastic coated, with pulley box. Meet different users to install various types of stepper or servo drive unit and to support a variety of external software systems. SIEMENS GSK can be installed or the system drive. Laboratory, teaching, and many economic applications factory ideal.
Item
Parameter
Max.drilling capacity(iron/steel)
31.5/40mm
Max.mill capacity(face/end)
80/32mm
Worktable size
240*800mm
X/Y/Z axis travel
500/290/350mm
T-slot(amount/size/space)
3/14/80mm
Spindle nose to surface of table
450mm
Spindle center to column surface
285mm
Max. face mill
ф60mm
Spindle taper
MT4/MT3/R8
Spindle speed range
1:80~980 RPM 2:1000~3000 RPM
Main motor
1.1KW
Positioning accuracy
0.015mm/300mm
Repeatability accuracy
±0.005mm
CNC Controller
GSK928MA/SIEMENS802S
X/Y/Z Rapid feed
3500/3000/2500mm/min
Packing size
1125×1105×1800mm
Machine weight
800/900KG
